Euclid Aquaseal Gel Light Gray 4 Gallon Unit
Euclid Aquaseal Gel is a two-part 100% solids non-sag epoxy paste in a 4 gallon case for underwater repair on concrete or masonry in fresh or saltwater. It stays on vertical and overhead work below the waterline and is the paste grade of Euclid's Aquaseal underwater epoxy system.
- Holds vertical and overhead underwater patches without sagging off the substrate.
- Fills granite block joints and packs horizontal anchor-bolt holes below the waterline.
- Bonds concrete and masonry repairs in fresh or saltwater marine service.
$365.21
Euclid Aquaseal Gel - Underwater Epoxy Paste, Light Gray 4 Gallon
Euclid Aquaseal Gel is a two-part 100% solids non-sag epoxy paste in a light gray 4 gallon case for underwater repair on concrete or masonry in fresh or saltwater. It is the paste grade of Euclid's Aquaseal underwater epoxy coating and repair system, and it meets ASTM C881 Type IV, Grade 3, Class C. It is placed on vertical and overhead patches, granite pointing, marine piers and piles, and packing horizontal anchor-bolt holes below the waterline.
Looking for the coating grade?
Key Features
- Two-part 100% solids non-sag epoxy paste for underwater concrete and masonry repair.
- Stays in place on vertical and overhead work below the waterline.
- The TDS lists ASTM C881 Type IV, Grade 3, Class C for Aquaseal Gel.
- The paste mixes at a 1 to 1 volume ratio; clean dry silica may extend it up to 1 to 1 binder to aggregate.
- Compressive strength is approximately 7,000 to 8,000 psi neat by ASTM D695.
- Light gray paste suits piers, piles, granite block pointing, and submerged patching.
Technical Specifications
| Property | Value |
|---|---|
| Catalog / Euclid code | Aquaseal Gel / TD5302104501 |
| Packaging | 4 gallon case |
| Chemistry | Two-part 100% solids non-sag epoxy paste |
| ASTM C881 | Type IV, Grade 3, Class C |
| Mix ratio | 1:1 by volume |
| Consistency | Gel (non-sag) |
| Compressive strength | Approximately 7,000 to 8,000 psi (ASTM D695) |
| Shore D hardness | Approximately 85 to 90 |
| Application temperature | 55°F (13°C) and rising |
| Shelf life | 2 years in original unopened packaging |
Product documents: Aquaseal Epoxy System Technical Data Sheet
Frequently Asked Questions
What jobs is Euclid Aquaseal Gel made for?
Euclid Aquaseal Gel is the non-sag underwater epoxy paste in the Aquaseal family for concrete or masonry in fresh or saltwater. The TDS names vertical and overhead patching, grouting and pointing of granite block, marine pier and pile repair, and packing horizontal anchor-bolt holes.
What ASTM C881 listing does Aquaseal Gel meet?
The Aquaseal Epoxy System TDS lists Aquaseal Gel as ASTM C881 Type IV, Grade 3, Class C. That is the paste grade beside MV coating and LV low-viscosity resin.
What mix ratio and working time apply to Aquaseal Gel?
Mix Part A and Part B 1 to 1 by volume. Gel time is approximately 60 minutes on a 100 g mass, and pot life is approximately 30 to 35 minutes in a 2 gallon unit at laboratory conditions. For mortar, the TDS allows clean dry silica up to 1:1 binder to aggregate by volume.
What strength does the TDS list for Aquaseal Gel?
Neat compressive strength is approximately 7,000 to 8,000 psi (ASTM D695). Mortar compressive strength with sand is approximately 8,000 to 9,000 psi (ASTM C109). Shore D hardness is approximately 85 to 90.
What temperature window applies when placing Aquaseal Gel?
Apply when water and surface temperatures are at least 55 F (13 C) and rising. Store between 50 F and 90 F. Do not mix and apply below 55 F.
Which other Aquaseal grades sit with this paste?
Aquaseal MV is the high-build underwater coating grade. Aquaseal LV is the low-viscosity grade for mortar and pressure injection. The live sister on Indcon Supply is Aquaseal MV Light Gray 4 gallon.
