Euclid Aquaseal MV Light Gray 4 Gallon Case
Euclid Aquaseal MV is a two-part 100% solids high-build epoxy coating in a 4 gallon case for concrete and masonry below water in fresh or saltwater. It is the medium-viscosity grade of Euclid's Aquaseal underwater epoxy system and builds a protective film on piers, piles, and other submerged structures.
- Protects concrete and steel below the waterline with a high-build underwater epoxy coating.
- Coats submerged piers, piles, and marine structures in fresh or saltwater service.
- Seals submerged concrete and steel after a scrub coat displaces surface water.
$365.21
Availability:
Out of stock
Euclid Aquaseal MV - Underwater Epoxy Coating, Light Gray 4 Gallon
Euclid Aquaseal MV is a two-part 100% solids high-build epoxy coating in a light gray 4 gallon case for concrete and masonry below water in fresh or saltwater. It is the medium-viscosity grade of Euclid's Aquaseal underwater epoxy coating and repair system, and it meets ASTM C881 Type IV, Grade 2, Class C. Contractors place it on submerged piers, piles, and similar marine structures when a high-build protective coating is needed under the waterline.
Looking for the paste grade?
Key Features
- Two-part 100% solids epoxy coating for underwater concrete and masonry.
- High-build protective film for structures below the waterline in fresh or saltwater.
- The TDS lists ASTM C881 Type IV, Grade 2, Class C for Aquaseal MV.
- The coating mixes at a 1 to 1 volume ratio for underwater placement on prepared substrates.
- First coat covers approximately 50 sq ft per gallon; second coat approximately 75 sq ft per gallon.
- Light gray coating suits piers, piles, and other submerged marine structures.
Technical Specifications
| Property | Value |
|---|---|
| Catalog / Euclid code | Aquaseal MV / TD2301104501 |
| Packaging | 4 gallon case |
| Chemistry | Two-part 100% solids epoxy coating |
| ASTM C881 | Type IV, Grade 2, Class C |
| Mix ratio | 1:1 by volume |
| Viscosity (mixed) | Approximately 5,000 to 7,000 cps |
| Compressive strength | Approximately 7,000 to 8,000 psi (ASTM D695) |
| Coverage (1st / 2nd coat) | Approximately 50 / 75 sq ft per gallon |
| Application temperature | 55°F (13°C) and rising |
| Shelf life | 2 years in original unopened packaging |
Product documents: Aquaseal Epoxy System Technical Data Sheet
Frequently Asked Questions
What jobs is Euclid Aquaseal MV made for?
Euclid Aquaseal MV is the high-build underwater epoxy coating in the Aquaseal family for concrete and masonry below water in fresh or saltwater. The TDS names coating of concrete and steel piers and piles and other submerged structures that need a protective film.
What ASTM C881 listing does Aquaseal MV meet?
The Aquaseal Epoxy System TDS lists Aquaseal MV as ASTM C881 Type IV, Grade 2, Class C. That is the medium-viscosity coating grade in the family beside LV and Gel.
What mix ratio and pot life apply to Aquaseal MV?
Mix Part A and Part B 1 to 1 by volume. Gel time is approximately 60 minutes on a 100 g mass, and pot life is approximately 30 to 40 minutes in a 2 gallon unit at laboratory conditions. Condition material to approximately 75 F for 24 hours before mixing when practical.
What coverage does the TDS list for Aquaseal MV coats?
Bond or primer coat approximately 100 sq ft per gallon, first coat approximately 50 sq ft per gallon, and second coat approximately 75 sq ft per gallon. A thin scrub coat displaces water before the heavier build coats.
What temperature window applies when placing Aquaseal MV?
Apply when water and surface temperatures are at least 55 F (13 C) and rising. Store between 50 F and 90 F. Do not mix and apply below 55 F.
Which other Aquaseal grades sit with this coating?
Aquaseal Gel is the non-sag paste grade for vertical and overhead underwater patches. Aquaseal LV is the low-viscosity grade for mortar and pressure-injection work. The live sister on Indcon Supply is Aquaseal Gel Light Gray 4 gallon.
