Sika Greenstreak Speed Load Dowel Sleeve 9in x 1/2in Smooth 18in Case 250 PSD1/2X9LT
Sika Greenstreak Speed Load PSD1/2X9LT is a case of 250 sleeves for 1/2 in by 18 in smooth dowels. The 9 in self-locking sleeve passes through expansion board and holds the bar for load transfer.
- Expansion-joint sleeve for 1/2 in by 18 in smooth dowels
- 9 in self-locking body passes through pre-drilled board
- Case of 250 sleeves for expansion joint work
$385.88
Availability:
In stock
( 5 Available )
Sika Greenstreak Speed Load PSD1/2X9LT
Sika Greenstreak Speed Load is a single-component polypropylene sleeve that positions round dowels through expansion board. This case of 250 PSD1/2X9LT sleeves (part 419189) takes 1/2 in by 18 in smooth dowels with a 9 in sleeve. The self-locking body passes through a pre-drilled board so the bar stays aligned for load transfer at the expansion joint.
Key Features
- Speed Load sleeve PSD1/2X9LT
- Fits 1/2 in by 18 in smooth dowels
- Sleeve length 9 in
- Self-locking body for pre-drilled expansion board
- Case of 250 sleeves
- Used for load transfer at expansion joints
Applications
- Expansion joints in industrial concrete slabs
- Pavement joints with polypropylene expansion board
- Site slabs that take 1/2 in smooth dowels through board
- Load-transfer joints where a construction-joint Speed Dowel is not used
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | Speed Load PSD1/2X9LT |
| Part no. | 419189 |
| Unit | Case of 250 sleeves |
| Dowel size | 1/2 in x 18 in smooth |
| Sleeve length | 9 in |
| Material | 100% polypropylene |
| Sleeve thickness | 0.075 in |
| Compressibility | 5,500-8,000 psi (ASTM D695) |
| System | Single-component sleeve for expansion joints |
Product documents: Sika Speed Dowel Systems Brochure (PDF)
Frequently Asked Questions
What bars fit Sika Greenstreak Speed Load PSD1/2X9LT?
1/2 in by 18 in smooth dowels, with a 9 in sleeve.
What size is Sika Greenstreak Speed Load PSD1/2X9LT?
The case is 250 sleeves, part 419189.
What joint work uses Sika Greenstreak Speed Load PSD1/2X9LT?
Expansion joints. The sleeve passes through pre-drilled expansion board and self-locks to keep the dowel aligned.
What sleeve length is Sika Greenstreak Speed Load PSD1/2X9LT?
9 in. Sibling Speed Load sleeves cover 1/2 in x 10 in (5 in sleeve) and larger diameters.
What board install does Sika Greenstreak Speed Load PSD1/2X9LT use?
A pre-drilled expansion board. The self-locking sleeve passes through the board; no Speed Dowel base is used.
What thickness is Sika Greenstreak Speed Load PSD1/2X9LT?
Nominal sleeve wall 0.075 in, thinner than the 0.125 in Speed Dowel construction-joint sleeve.
