Sika Greenstreak Flexible PVC Waterstop Ribbed Centerbulb 735 9" x 3/8" 50ft Roll 419524
Sika Greenstreak 735 is a 9 in x 3/8 in PVC ribbed-centerbulb waterstop in a 50 ft roll. It is used on moving concrete joints.
- Larger centerbulb for greater movement
- Watertight diaphragm through the joint
- NSF/ANSI 61 for potable water contact
$583.94
Availability:
In stock
( 5 Available )
735 Ribbed Centerbulb, 9 in x 3/8 in, 50 ft roll
Sika Greenstreak 735 is a flexible PVC waterstop, ribbed centerbulb, for moving concrete joints. It is used at water and wastewater plants, lock and dam systems, reservoirs, flood walls, retaining walls, foundations, tunnels, culverts, bridge abutments, tanks, and slabs on ground. It is placed in the joint before the concrete. The centerbulb accommodates lateral, transverse, and shear movement.
Key Features
- Flexible PVC ribbed-centerbulb waterstop
- Larger centerbulb for greater movement
- Watertight diaphragm through the joint
- NSF/ANSI 61 for potable water contact
- Meets CRD-C 572-74
Applications
- Water and wastewater plants.
- Lock and dam systems, reservoirs, and flood walls.
- Retaining walls, foundations, tunnels, and culverts.
- Bridge abutments, tanks, and slabs on ground.
Technical Specifications
| Property | Value |
|---|---|
| Pack | 9 in x 3/8 in, 50 ft roll |
| Weight | 2.45 lb/ft (3.65 kg/m) |
| Size | 9 in x 3/8 in x 1/8 in; centerbulb 1/2 in ID x 1 in OD |
| Head | 175 ft (523 kPa), ultimate; apply a safety factor |
| Shore A | 79 ± 3, ASTM D2240 |
| Tensile | 2000 psi min, ASTM D638 |
| Elongation | 350%, ASTM D638 |
| Tear | 300 lb/in min, ASTM D624 |
| Low-temperature brittleness | passes at -35 F, ASTM D746 |
| NSF/ANSI | Standard 61 |
Documents
Greenstreak PVC Waterstop Product Data Sheet
Frequently Asked Questions
What 9-inch size is Sika Greenstreak 735?
9 in x 3/8 in, 50 ft roll.
What is the 2.45-pound weight of Sika Greenstreak 735?
2.45 lb/ft (3.65 kg/m).
What is the 175-foot head of Sika Greenstreak 735?
175 ft (523 kPa), ultimate. Apply a safety factor.
What is the tensile strength of Sika Greenstreak 735?
2000 psi min, ASTM D638.
What is the tear of Sika Greenstreak 735?
300 lb/in min, ASTM D624.
What is the low-temperature rating of Sika Greenstreak 735?
Passes at -35 F, ASTM D746.
