Sika Greenstreak Speed Load Dowel Sleeve 6 Rebar or 7/8 Smooth x 18 Case 200
Sika Greenstreak Speed Dowel PSD09/#6TX is a case of 200 sleeves for #6 rebar or 7/8 in smooth 18 in dowels. The 9 in sleeve holds alignment so construction joints transfer load without a drilled first pour.
- Slip-dowel sleeve for #6 rebar or 7/8 in smooth 18 in bars
- 9 in sleeve keeps dowels aligned for load transfer
- Case of 200 sleeves for slab-on-ground joint work
$421.31
Availability:
In stock
( 1 Available )
Sika Greenstreak Speed Dowel PSD09/#6TX
Sika Greenstreak Speed Dowel is a polypropylene slip-dowel sleeve that keeps round dowels aligned for load transfer in construction joints. This case of 200 PSD09/#6TX sleeves (part 419185) takes #6 rebar or 7/8 in smooth dowels 18 in long with a 9 in sleeve. Nail the reusable base to the form, tap the sleeve onto the base, and pour; after strip the second-side dowel inserts without drilling the first slab.
Key Features
- Speed Dowel sleeve PSD09/#6TX
- Fits 7/8 in smooth or #6 rebar x 18 in
- Sleeve length 9 in; corresponding base PSD/#6BX
- Case of 200 sleeves
- Used for load transfer in slabs on grade
- Eliminates drilled first-pour dowel installs
Applications
- Construction joints in industrial concrete slabs
- Industrial floors and warehouse slabs
- Pavement and site slabs needing load transfer
- Round-dowel joints using #6 rebar or 7/8 in smooth bar
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | Speed Dowel PSD09/#6TX |
| Part no. | 419185 |
| Unit | Case of 200 sleeves |
| Dowel size | #6 rebar or 7/8 in smooth x 18 in |
| Sleeve length | 9 in |
| Base | PSD/#6BX |
| Material | 100% polypropylene |
| Sleeve thickness | 0.125 in |
| Compressibility | 5,500-8,000 psi (ASTM D695) |
Product documents: Sika Speed Dowel Systems Brochure (PDF)
Frequently Asked Questions
What bars fit Sika Greenstreak Speed Dowel PSD09/#6TX?
#6 rebar or 7/8 in smooth dowels 18 in long, with a 9 in sleeve.
What size is Sika Greenstreak Speed Dowel PSD09/#6TX?
The case is 200 sleeves, part 419185.
What joint work uses Sika Greenstreak Speed Dowel PSD09/#6TX?
Construction joints in slabs on grade that need aligned slip dowels for positive load transfer.
What sleeve length is Sika Greenstreak Speed Dowel PSD09/#6TX?
9 in; the matching base is PSD/#6BX. The 12 in PSD12/#6TX sleeve is the 24 in dowel sibling.
What first-pour drilling does Sika Greenstreak Speed Dowel PSD09/#6TX replace?
The sleeve is nailed to the form and poured in place, so the second-side dowel inserts after strip without drilling the first slab.
What base goes with Sika Greenstreak Speed Dowel PSD09/#6TX?
Corresponding base PSD/#6BX from the Speed Dowel round-dowel table.
