Five Star LC Epoxy Grout
Five Star LC Epoxy Grout is a highly flowable, non-shrink, rapid strength gain, epoxy grout for tight clearance applications and dynamic loads. This versatile product is formulated for placement into low clearance applications as thin as 3/8 inches (10 mm) in depth dependent on specific placement requirements while achieving very high mechanical properties.
- High Flow for Tight Clearances
- Excellent Adhesion to Steel
- Rapid Strength Gain
$403.76
Five Star LC Epoxy Grout, High-Flow Tight Clearance Epoxy
Five Star LC Epoxy Grout is a highly flowable, non-shrink, rapid-strength epoxy grout for tight clearances and dynamic loads. The three-component, 100% solids system places as thin as 3/8 inch while still delivering high mechanical properties and high effective bearing. Use it on crane rails, light rail, transfer-car runways, and other low-clearance equipment.
Key Features
- High flow for tight clearances
- Places as thin as 3/8 inch
- Rapid strength gain for fast turnaround
- 95% effective bearing area with proper placement
- Excellent adhesion to steel
- Positive expansion, non-shrink performance
Applications
- Tight-clearance grouting under dynamic loads
- Crane rails and light rail
- Railroad track rehabilitation
- Transfer-car runways
- Material-handling tracks
Technical Specifications
| Property | Value |
|---|---|
| Chemistry | Three-component, 100% solids epoxy grout |
| Yield | About 0.49 cu ft per unit |
| Compressive strength, 1 day | 13,000 psi |
| Compressive strength, 7 days | 15,000 psi |
| Compressive strength, 28 days | 16,000 psi |
| Effective bearing area | 95% |
| Working time at 70°F | 30 minutes |
| Minimum plate clearance | 3/8 in |
| Placement depth | 3/8 in to 3 in |
| Maximum in-service temperature | 180°F |
| Bond to concrete, 7 days | 3,000 psi |
| Flexural strength | 5,500 psi |
Product documents: LC Epoxy Grout Technical Data Sheet (PDF)
Frequently Asked Questions
How thin can Five Star LC Epoxy Grout be placed?
Five Star LC Epoxy Grout is a high-flow epoxy for tight clearances as thin as 3/8 inch.
Is Five Star LC Epoxy Grout used on crane rails?
Yes. Five Star LC Epoxy Grout is used on crane rails, light-rail applications, railroad-track rehabilitation, transfer-car runways, and material-handling tracks.
How strong is Five Star LC Epoxy Grout at one day?
Five Star LC Epoxy Grout typically reaches about 13,000 psi at one day at 70 F.
When should a contractor pick Five Star LC Epoxy Grout instead of Five Star HP Epoxy Grout?
Pick Five Star LC Epoxy Grout for high-flow, low-clearance work down to 3/8 inch on crane rails and dynamic tracks. Use Five Star HP Epoxy Grout High Flow when you need a precision machinery grout with 1-inch minimum plate clearance and 16-hour start-up.
Does Five Star LC Epoxy Grout reach 95 percent effective bearing area?
Yes. Five Star LC Epoxy Grout typically reaches 95 percent effective bearing area when placed correctly and shows positive expansion when tested to ASTM C827.
Is Five Star LC Epoxy Grout chemically resistant?
Yes. Five Star LC Epoxy Grout has excellent chemical resistance and excellent adhesion to steel under dynamic load.
