Sika Greenstreak X-Plug XP003 3/4 to 1-1/4 White Pail 500
Sika Greenstreak X-Plug XP003 is a mechanical EPDM plug in a white pail of 500 for 3/4 in to 1-1/4 in taper ties. Tightening the stainless nut expands the rubber so the void seals liquid-tight.
- Mechanical plug for 3/4 in to 1-1/4 in taper-tie voids
- EPDM expands as the stainless nut tightens
- White pail of 500 plugs, the largest count in the range
$2,066.15
Sika Greenstreak X-Plug XP003
Sika Greenstreak X-Plug XP003 is a mechanical EPDM plug with a 304 stainless bolt that seals taper-tie voids in water-retaining walls. This white pail of 500 (part 420801) fits 3/4 in to 1-1/4 in taper ties. Tightening the nut expands the rubber against the void wall for a liquid-tight seal that holds nearly 300 ft of head without grout on both faces.
Key Features
- X-Plug XP003 mechanical taper-tie plug
- Fits 3/4 in to 1-1/4 in taper ties
- White pail of 500, part 420801
- EPDM rubber expands as the 304 stainless nut tightens
- Seals the void without grout on either side
- White pail is the 500-count size in the X-Plug range
Applications
- Taper-tie voids in water-retaining walls
- Pass-through tie sleeves after the rod is pulled
- Tanks, vaults, and below-grade walls
- Water-excluding structures that need a mechanical plug
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | X-Plug XP003 |
| Part no. | 420801 |
| Unit | White pail of 500 |
| Taper tie size | 3/4 in to 1-1/4 in |
| Pail color | White |
| Bolt | 304 stainless with Xylan coating |
| Water absorption | < 3.5% (ASTM D471) |
| Seat depth | 50-60% of wall thickness when sized correctly |
| Head pressure | Nearly 300 ft without grout on either side |
Product documents: Sika X-Plug Product Data Sheet (PDF)
Frequently Asked Questions
What taper ties fit Sika Greenstreak X-Plug XP003?
3/4 in to 1-1/4 in taper ties. White is the widest size band and the 500-count pail.
What size is Sika Greenstreak X-Plug XP003?
The pail is 500 plugs, part 420801.
What debris prep does Sika Greenstreak X-Plug XP003 need?
Clear loose debris from the void. A taper-tie void brush from Sika Greenstreak is recommended before the plug is seated.
What water absorption is Sika Greenstreak X-Plug XP003?
Less than 3.5% (ASTM D471) on the EPDM body.
What joint work uses Sika Greenstreak X-Plug XP003?
Taper-tie and pass-through sleeve voids in walls of water-retaining or water-excluding structures.
What grout does Sika Greenstreak X-Plug XP003 need?
None for the seal. After the nut is tight, grout may be packed in the remaining void for appearance only.
