Sika Greenstreak X-Plug XP002 1 to 1-1/4 Red Pail 400
Sika Greenstreak X-Plug XP002 is a mechanical EPDM plug in a red pail of 400 for 1 in to 1-1/4 in taper ties. Tightening the stainless nut expands the rubber so the void seals liquid-tight.
- Mechanical plug for 1 in to 1-1/4 in taper-tie voids
- EPDM expands as the stainless nut tightens
- Red pail of 400 plugs for water-retaining walls
$1,760.00
Sika Greenstreak X-Plug XP002
Sika Greenstreak X-Plug XP002 is a mechanical EPDM plug with a Xylan-coated 304 stainless bolt that seals taper-tie voids in water-retaining walls. This red pail of 400 (part 420800) fits 1 in to 1-1/4 in taper ties. Tightening the nut expands the rubber against the void wall for a liquid-tight seal that holds nearly 300 ft of head without grout on both faces.
Key Features
- X-Plug XP002 mechanical taper-tie plug
- Fits 1 in to 1-1/4 in taper ties
- Red pail of 400, part 420800
- EPDM rubber expands as the 304 stainless nut tightens
- Seals the void without grout on either side
- Holds nearly 300 ft of head pressure
Applications
- Taper-tie voids in water-retaining walls
- Pass-through tie sleeves after the rod is pulled
- Tanks, vaults, and below-grade walls
- Water-excluding structures that need a mechanical plug
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | X-Plug XP002 |
| Part no. | 420800 |
| Unit | Red pail of 400 |
| Taper tie size | 1 in to 1-1/4 in |
| Pail color | Red |
| Bolt | 304 stainless with Xylan coating |
| Head pressure | Nearly 300 ft without grout on either side |
| Seat depth | 50-60% of wall thickness when sized correctly |
| EPDM tensile | 13.2 MPa (ASTM D412) |
Product documents: Sika X-Plug Product Data Sheet (PDF)
Frequently Asked Questions
What taper ties fit Sika Greenstreak X-Plug XP002?
1 in to 1-1/4 in taper ties. The red pail sits between XP001 (black, larger) and XP003 (white, smaller).
What size is Sika Greenstreak X-Plug XP002?
The pail is 400 plugs, part 420800.
What spinning does Sika Greenstreak X-Plug XP002 prevent?
The 304 stainless bolt is compression-set at 50 lb into the EPDM grommet so the bolt does not spin while the nut is tightened.
What coating is Sika Greenstreak X-Plug XP002?
Xylan on the stainless bolt, rated for an extra 500 to 1,000 hours in ASTM B117 salt spray.
What install tool does Sika Greenstreak X-Plug XP002 use?
A 7/16 in extension on a handheld drill. Place the nut side in the socket, slide to the seat, and fully tighten the nut.
What grout does Sika Greenstreak X-Plug XP002 need?
None for the seal. After the nut is tight, grout may be packed in the remaining void for appearance only.
