Sika Greenstreak Speed Dowel Number 5 Base 200 per Carton 419171
Sika Greenstreak Speed Dowel PSD/#5BX is a carton of 200 reusable bases for #5 rebar or 3/4 in smooth sleeves. The base nails to the form so the matching sleeve holds alignment for load transfer at the joint.
- Reusable base for #5 rebar or 3/4 in smooth Speed Dowel sleeves
- Nails to the edge form before the first pour
- Carton of 200 bases; sleeves are sold separately
$118.18
Availability:
In stock
( 3 Available )
Sika Greenstreak Speed Dowel PSD/#5BX
Sika Greenstreak Speed Dowel PSD/#5BX is the reusable polypropylene base that locates PSD09/#5TX and PSD12/#5TX sleeves on the form. This carton of 200 bases (part 419171) is for #5 rebar or 3/4 in smooth dowels. Nail the base to the edge form, tap the matching sleeve onto it, and pour; after strip the base comes off with the form and can be reused on the next joint.
Key Features
- Speed Dowel base PSD/#5BX
- Fits #5 rebar or 3/4 in smooth sleeves
- Works with PSD09/#5TX (18 in) and PSD12/#5TX (24 in)
- Reusable polypropylene base
- Carton of 200 bases
- Sleeves are sold separately
Applications
- Construction joints using #5 rebar or 3/4 in smooth dowels
- Industrial floors and warehouse slabs
- Pavement and site slabs needing load transfer
- First-pour form setup for Speed Dowel sleeves
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | Speed Dowel PSD/#5BX |
| Part no. | 419171 |
| Unit | Carton of 200 bases |
| Fits | #5 rebar or 3/4 in smooth sleeves |
| Matching sleeves | PSD09/#5TX and PSD12/#5TX |
| Material | 100% polypropylene |
| Reuse | Bases are reusable; sleeves are sold separately |
Product documents: Sika Speed Dowel Systems Brochure (PDF)
Frequently Asked Questions
What sleeves fit Sika Greenstreak Speed Dowel PSD/#5BX?
PSD09/#5TX 9 in sleeves for 18 in bars and PSD12/#5TX 12 in sleeves for 24 in bars, both #5 rebar or 3/4 in smooth.
What size is Sika Greenstreak Speed Dowel PSD/#5BX?
The carton is 200 bases, part 419171.
What joint work uses Sika Greenstreak Speed Dowel PSD/#5BX?
First-pour form setup on construction joints that take #5 rebar or 3/4 in smooth slip dowels.
What reuse does Sika Greenstreak Speed Dowel PSD/#5BX allow?
The base stays on the form at strip and can be reused; sleeves stay in the first-pour concrete.
What first-pour drilling does Sika Greenstreak Speed Dowel PSD/#5BX replace?
The base is nailed to the form and the sleeve is tapped on, so the first slab is not drilled for dowels.
What sleeves ship with Sika Greenstreak Speed Dowel PSD/#5BX?
None. Sleeves are sold separately from the base carton.
