Sika Greenstreak Flexible PVC Waterstop Ribbed Centerbulb 717 6in x 3/8in 50ft Roll 419482
Sika Greenstreak PVC Waterstop 717 is a ribbed centerbulb profile in a 6 in by 3/8 in 50 ft roll. The larger 1/2 in by 1 in bulb takes joint movement while the ribs lock a watertight diaphragm in place.
- Ribbed centerbulb profile for moving joints
- 6 in by 3/8 in web with 1/2 in ID by 1 in OD bulb
- 50 ft roll, rated 125 ft of hydrostatic head
$365.36
Availability:
In stock
( 7 Available )
Sika Greenstreak PVC Waterstop 717
Sika Greenstreak Flexible PVC Waterstop profile 717 is a ribbed centerbulb PVC strip for embedded joint waterproofing in cast-in-place concrete. This 6 in by 3/8 in RCB profile ships as a 50 ft roll (part 419482) and forms a watertight diaphragm across construction and expansion joints. The 1/2 in by 1 in centerbulb takes more movement than the thinner 703 while the ribs lock into the concrete.
Key Features
- Flexible PVC waterstop, profile 717 ribbed centerbulb (RCB)
- Profile width 6 in with 3/8 in web thickness
- Centerbulb 1/2 in ID by 1 in OD
- Weight approximately 1.52 lb/ft
- Head pressure 125 ft (373 kPa)
- NSF/ANSI 61 approved for potable water contact
Applications
- Construction and expansion joints under higher head
- Water and wastewater treatment plants
- Tunnels, culverts, lock and dam systems
- Tanks, reservoirs, and flood walls
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | Flexible PVC Waterstop 717 RCB |
| Part no. | 419482 |
| Unit | 50 ft roll |
| Profile | 6 in x 3/8 in ribbed centerbulb |
| Centerbulb | 1/2 in ID x 1 in OD |
| Weight | Approximately 1.52 lb/ft |
| Head pressure | 125 ft (373 kPa) |
| Tensile strength | 2,000 psi min (ASTM D638) |
| Elongation | 350% (ASTM D638) |
| Shore A | 79 +/- 3 (ASTM D2240) |
| Potable water | NSF/ANSI 61 |
Product documents: Greenstreak PVC Waterstop Product Data Sheet (PDF)
Frequently Asked Questions
What joints suit Sika Greenstreak PVC Waterstop 717?
Construction and expansion joints that need a 6 in by 3/8 in ribbed centerbulb with a 1/2 in by 1 in bulb.
What size is Sika Greenstreak PVC Waterstop 717?
The roll is 50 ft of 6 in by 3/8 in RCB profile, part 419482.
What centerbulb is Sika Greenstreak PVC Waterstop 717?
1/2 in ID by 1 in OD, larger than 703 (1/4 by 5/8) and 732 (5/16 by 7/8).
What head pressure does Sika Greenstreak PVC Waterstop 717 hold?
125 ft (373 kPa). Weight is approximately 1.52 lb/ft.
What 732 difference does Sika Greenstreak PVC Waterstop 717 have?
Both are 6 in by 3/8 in 50 ft RCB rolls at 125 ft head. 717 uses the 1/2 in by 1 in bulb; 732 uses 5/16 in by 7/8 in and is slightly heavier.
What splice method does Sika Greenstreak PVC Waterstop 717 use?
Heat-welded splices with a Sika Greenstreak splicing iron. Factory fabrications are recommended for intersections.
