Sika Greenstreak Flexible PVC Waterstop Ribbed Centerbulb 703 6in x 3/16in RCB 100ft Roll 419436
Sika Greenstreak PVC Waterstop 703 is a ribbed centerbulb profile in a 6 in by 3/16 in 100 ft roll. Embedded across the joint, the bulb takes movement while the ribs lock a watertight diaphragm in place.
- Ribbed centerbulb profile for moving joints
- 6 in by 3/16 in web, 1/4 in ID by 5/8 in OD bulb
- 100 ft roll, rated 100 ft of hydrostatic head
$344.15
Availability:
In stock
( 6 Available )
Sika Greenstreak PVC Waterstop 703
Sika Greenstreak Flexible PVC Waterstop profile 703 is a ribbed centerbulb PVC strip for embedded joint waterproofing in cast-in-place concrete. This 6 in by 3/16 in RCB profile ships as a 100 ft roll (part 419436) and forms a watertight diaphragm across construction and expansion joints. The centerbulb takes movement while the ribs lock into the concrete in water plants, tunnels, and tanks.
Key Features
- Flexible PVC waterstop, profile 703 ribbed centerbulb (RCB)
- Profile width 6 in with 3/16 in web thickness
- Centerbulb 1/4 in ID by 5/8 in OD
- Weight approximately 0.73 lb/ft
- Head pressure 100 ft (299 kPa)
- NSF/ANSI 61 approved for potable water contact
Applications
- Construction and expansion joints in water plants
- Tunnels, culverts, lock and dam systems
- Foundations, retaining walls, and flood walls
- Containment structures and tanks
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | Flexible PVC Waterstop 703 RCB |
| Part no. | 419436 |
| Unit | 100 ft roll |
| Profile | 6 in x 3/16 in ribbed centerbulb |
| Centerbulb | 1/4 in ID x 5/8 in OD |
| Weight | Approximately 0.73 lb/ft |
| Head pressure | 100 ft (299 kPa) |
| Tensile strength | 2,000 psi min (ASTM D638) |
| Elongation | 350% (ASTM D638) |
| Shore A | 79 +/- 3 (ASTM D2240) |
| Potable water | NSF/ANSI 61 |
Product documents: Greenstreak PVC Waterstop Product Data Sheet (PDF)
Frequently Asked Questions
What joints suit Sika Greenstreak PVC Waterstop 703?
Construction and expansion joints that need a 6 in ribbed centerbulb diaphragm, not a dumbbell for non-moving joints.
What size is Sika Greenstreak PVC Waterstop 703?
The roll is 100 ft of 6 in by 3/16 in RCB profile, part 419436.
What centerbulb is Sika Greenstreak PVC Waterstop 703?
1/4 in ID by 5/8 in OD. The bulb takes joint movement; the ribs lock into the concrete.
What head pressure does Sika Greenstreak PVC Waterstop 703 hold?
100 ft (299 kPa) from the Greenstreak profile table.
What potable-water approval does Sika Greenstreak PVC Waterstop 703 hold?
Suitable for potable water contact and meets NSF/ANSI Standard 61.
What weight is Sika Greenstreak PVC Waterstop 703?
Approximately 0.73 lb/ft.
