Sylmasta SylWrap Cast Iron Pipe Repair Kit 100mm
Repair kit for cracked cast iron and plastic waste pipes, effective even when water is leaking through. Repairs can be made in under 30 minutes to pipe diameters between 1 1/4 and 6 inches.
- Seal leaks in under 30 minutes
- Convenient kit packaging
- Repairs active leaks
$294.47
Availability:
In stock
( 10 Available )
SKU
22640
Sylmasta SylWrap Cast Iron Pipe Repair Kit – 100 mm
This 100 mm Cast Iron Pipe Repair Kit seals cracks and splits in cast iron drain, waste, soil, and supply pipes without hot work. The system combines Superfast Epoxy Putty for small holes, CrackSeal cartridge sealant for longer cracks, and a SylWrap HD composite bandage to overwrap and reinforce the repair. Installs in under 30 minutes and cures to a permanent, impact-resistant finish; components noted are WRAS approved for use on potable water systems.
Key Features
- Permanently repairs cast iron pipe cracks and splits in under 30 minutes.
- Two sealing options: kneadable epoxy putty for holes; CrackSeal for long cracks.
- Overwrap with SylWrap HD bandage; sets in ~5 minutes to a tough protective shell.
- Effective on elbows, tees, saddles, and confined spaces.
- Repairs are pressure resistant up to 30 bar and temperature resistant to 200°C once cured (application is for no-pressure conditions).
- Superfast Epoxy Putty and SylWrap HD are WRAS approved for drinking water systems.
- Simple process—no special training required; cost-effective alternative to replacement.
- White bandage standard; black bandage available on request for visual uniformity on black pipework.
Applications
- Cast iron rainwater stacks, downpipes, and soil lines.
- Drain and waste pipework in hospitals, offices, car parks, and other public or commercial buildings.
- Repairs around joints and fittings: elbows, tees, and saddles.
- Interior or exterior sections where access is limited.
Technical Specifications
| Kit Coverage (this item) | Designed for 100 mm pipe OD |
| Core Components | Superfast Epoxy Putty; CrackSeal Sealant (cartridge applied); SylWrap HD Pipe Repair Bandage |
| Package Contents (100 mm kit) | 1 × SYL616HD bandage (100 mm × 5.0 m); 1 × CrackSeal 310 ml cartridge; Superfast Epoxy Putty |
| Working / Functional / Full Cure | Bandage working time ~2–5 minutes; functional cure ~30–45 minutes; full cure ~24 hours |
| Pressure / Temperature (cured repair) | Up to 30 bar; up to 200°C service |
| Approvals | Superfast Epoxy Putty and SylWrap HD: WRAS approved (potable water) |
| Bandage Color | White standard; black available on request |
| Storage / Shelf Life | Store cool and dry; keep bandage sealed in foil pouch. Shelf life ≥24 months unopened |
Frequently Asked Questions
Is the kit for live leaks?
The cast iron kit is intended for no-pressure applications. Once cured, the repair is pressure-resistant, but isolate flow during installation whenever possible.
How do I choose between putty and CrackSeal?
Use Superfast Epoxy Putty to plug small holes or short defects. Use CrackSeal for long, narrow cracks—gun directly into the crack until filled, then overwrap.
Why is the bandage needed?
SylWrap HD consolidates and protects the seal, forming a tough, impact-resistant composite shell in about five minutes.
Can I use it on fittings and tight spaces?
Yes. The kit is effective around elbows, tees, and other difficult-to-access sections.
Are the materials drinking-water safe?
Superfast Epoxy Putty and SylWrap HD carry WRAS approval for potable water systems.
Any storage tips?
Keep the bandage in its sealed foil pouch until use to prevent premature cure; store all items cool and dry.
