Simpson Strong-Tie Drop-In (DIAB) Internally Threaded Anchor 5/8 Case 25 DIAB62
DIAB 5/8 in flush drop-in, model DIAB62. Zinc-plated carbon steel. Box of 25. Drill 7/8 in. UNC 11 thread.
- 5/8 in flush, model DIAB62, box of 25
- Drill 7/8 in; set until the tool shoulder seats
- No live 5/8 lipped or coil-thread drop-in
$35.04
Availability:
In stock
Drop Shipped DIAB Drop-In Anchor 5/8, DIAB62
DIAB is a zinc-plated carbon steel internally threaded drop-in for solid concrete. This 5/8 in flush insert, model DIAB62, ships a 25-count box. Drill 7/8 in to the 2 1/2 in body length, set flush, and drive the plug until the setting-tool shoulder seats. UNC 11 threads. Live flush sizes are 3/8, 1/2, 5/8, and 3/4. There is no live 5/8 lipped or coil-thread drop-in.
Looking for another size?
Key Features
- Internally threaded drop-in for solid concrete
- 5/8 in flush, model DIAB62, box of 25
- Drill 7/8 in to 2 1/2 in body length; UNC 11
- Set with the matching setting tool until the shoulder seats
- Live flush sizes 3/8, 1/2, 5/8, and 3/4
Applications
- Flush-mount threaded rod in concrete
- Overhead hanger rod
- Fixtures that take a 5/8 in UNC bolt
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Simpson Strong-Tie |
| Product | DIAB Drop-In |
| Model | DIAB62 |
| Rod | 5/8 in UNC 11 |
| Drill bit | 7/8 in |
| Body length | 2 1/2 in |
| Box qty | 25 |
| Style | Flush |
| Coating | Zinc-plated carbon steel |
| Not | Lipped or coil-thread |
Frequently Asked Questions
What is this?
A 5/8 in flush DIAB drop-in, model DIAB62, box of 25. Internally threaded for 5/8 in UNC rod.
How do I set it?
Drill 7/8 in to the 2 1/2 in body length, tap the insert flush, then drive the setting tool until the shoulder seats.
Lipped or coil 5/8?
Not live. Flush 5/8 is this page.
What other flush sizes are live?
3/8, 1/2, 5/8, and 3/4. There is no live 1/4 flush DIAB.
Who makes it?
Simpson Strong-Tie.
