Sika Greenstreak 655 PVC Retrofit System 10ft Piece
Sika Greenstreak 655 is a 3 inch PVC retrofit waterstop in a 10 ft piece. It seals joints where new concrete meets an existing structure.
- Seals new-to-existing joints
- Stainless batten and bolts fasten the 3 inch profile
- NSF/ANSI 61 for potable water contact
$394.68
Sika Greenstreak 655
Sika Greenstreak 655 is a flexible PVC retrofit waterstop with stainless batten and bolts. This 10 ft piece is the 3 inch profile at 1.38 lb/ft with hardware, for joints where new construction meets an existing structure. Epoxy 7300 gel bonds the flange to the existing concrete face. It is used at water and wastewater plants, reservoirs, foundations, tunnels, and tanks.
Key Features
- 3 inch PVC retrofit waterstop, 10 ft piece
- 1.38 lb/ft with hardware
- Stainless batten and bolts
- Epoxy 7300 gel bonds the flange to the existing face
- NSF/ANSI 61 for potable water contact
- Meets CRD-C 572-74
Applications
- Joints where new construction meets an existing structure
- Water and wastewater plants, locks, dams, and reservoirs
- Flood walls, retaining walls, foundations, and tunnels
- Tanks and other water-retaining concrete
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | 655 PVC Retrofit System |
| Part no. | 705836 |
| Unit | 10 ft piece |
| Profile | 3 inch / 7/16 inch / 3 inch |
| Weight | 1.38 lb/ft with hardware |
| Shore A | 79 +/- 3, ASTM D2240 |
| Tensile | 2000 psi min, ASTM D638 |
| Elongation | 350%, ASTM D638 |
| NSF/ANSI | Standard 61 |
Product documents: Greenstreak PVC Waterstop Product Data Sheet (PDF)
Frequently Asked Questions
What joints use Sika Greenstreak 655?
Joints where new construction meets an existing structure, including water plants, reservoirs, foundations, tunnels, and tanks.
What size is Sika Greenstreak 655?
The piece is 10 ft. The 655 profile is 3 inch / 7/16 inch / 3 inch.
What profile does Sika Greenstreak 655 have?
3 inch, with 7/16 inch and 3 inch on the retrofit drawing.
What weight does Sika Greenstreak 655 have?
1.38 lb/ft (2.05 kg/m) with hardware.
What elongation does Sika Greenstreak 655 have?
350% (ASTM D638). Tear is 300 lb/in min (ASTM D624).
What epoxy gel does Sika Greenstreak 655 use?
Epoxy 7300 gel, with stainless batten and stainless bolts. The gel bonds the flange to the existing concrete face.
