Sika Greenstreak 581 PVC Retrofit System 10ft Piece

Sika Greenstreak 581 is a 3 11/16 in PVC retrofit waterstop in a 10 ft piece for joints where new concrete meets an existing structure. Stainless batten, bolts, and Epoxy 7300 gel fasten the profile to the existing face.

The profile seals new-to-existing construction joints
Stainless batten and bolts hold the waterstop on the existing face
The 10 ft piece is 1.51 lb/ft with hardware

$399.58

Details

Sika Greenstreak 581

Sika Greenstreak 581 is a flexible PVC retrofit waterstop in a 10 ft piece for joints where new construction meets an existing structure. Stainless batten, bolts, and Epoxy 7300 gel fasten the profile to the existing face so the new pour has a continuous waterstop. The 581 profile is 3 11/16 in and 1.51 lb/ft with hardware. It is used at water and wastewater plants, locks, dams, reservoirs, flood walls, foundations, tunnels, and tanks.

Key Features

3 11/16 in PVC retrofit waterstop in a 10 ft piece
The profile seals new-to-existing construction joints
Stainless batten and bolts hold the waterstop on the existing face
Epoxy 7300 gel bonds the profile to the existing concrete
NSF/ANSI 61 covers potable water contact

Applications

Joints where new construction meets an existing structure
Water and wastewater plants, locks, dams, and reservoirs
Flood walls, retaining walls, foundations, tunnels, and tanks

Technical Specifications

Property	Value
Piece	10 ft
Profile	3 11/16 in (3 1/8 in / 7/16 in / 3 11/16 in)
Weight	1.51 lb/ft with hardware
Hardware	Stainless batten, bolts, Epoxy 7300
Shore A	79 ± 3, ASTM D2240
Tensile	2000 psi min, ASTM D638
Elongation	350%, ASTM D638
Tear	300 lb/in min, ASTM D624
Low-temp brittleness	Passes at -35 F, ASTM D746
NSF/ANSI	Standard 61

Product documents: Greenstreak PVC Waterstop Product Data Sheet

Frequently Asked Questions

What joints is Sika Greenstreak 581 used on?
Joints where new construction meets an existing structure, including water and wastewater plants, locks, dams, reservoirs, flood walls, foundations, tunnels, and tanks. Stainless batten, bolts, and Epoxy 7300 gel fasten the profile to the existing face.

What size is Sika Greenstreak 581?
The 581 profile is 3 11/16 in, shown as 3 1/8 in / 7/16 in / 3 11/16 in, in a 10 ft piece.

What weight does Sika Greenstreak 581 have?
1.51 lb/ft (2.25 kg/m) with hardware. The 10 ft piece is 15.1 lb.

What hardness does Sika Greenstreak 581 have?
Shore A 79 ± 3 per ASTM D2240. Tensile is 2000 psi minimum and elongation is 350% per ASTM D638.

What epoxy gel is used with Sika Greenstreak 581?
Epoxy 7300 gel bonds the profile to the existing concrete. Stainless batten and bolts hold the waterstop on that face.

What potable-water listing does Sika Greenstreak 581 have?
NSF/ANSI Standard 61. The profile also meets CRD-C 572-74.
