Euclid E3 Xtreme Epoxy Grout 1.7 CF
Euclid E3-Xtreme is a three-component, high-flow, ultra-high-strength epoxy grout for pumps, rotating equipment, wind-turbine bases, crane rails, and other high dynamic loads. DL Technology aggregate cuts mixing dust.
- High dynamic load grouting under rotating equipment
- Greater than 95% effective bearing area and very low creep
- Place 1 to 6 in per lift
$474.92
Drop Shipped
Euclid E3-Xtreme Epoxy Grout, 1.7 CF Kit
Euclid E3-Xtreme is a three-component, high-flow, ultra-high-strength epoxy grout for pumps, rotating equipment, wind-turbine bases, crane rails, and other high dynamic loads. Patented DL Technology aggregate cuts the dust released while mixing and handling. Ultra-low creep and high early strength keep compressors, presses, and skid-mounted equipment aligned under those loads.
Key Features
- Ultra-high-strength high-flow epoxy grout for dynamic loads
- Greater than 95% effective bearing area
- Very low creep
- DL Technology aggregate cuts mixing dust
- Very high early strength for a fast return to service
- Place 1 to 6 in per lift
Applications
- Pumps and rotating equipment
- Wind-turbine bases and crane rails
- Compressors, turbo-machinery, and skid-mounted equipment
- Presses, stamping machines, and other high dynamic loads
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Euclid Chemical |
| Product | E3-Xtreme |
| Type | Ultra-high-performance epoxy grout with DL Technology aggregate |
| Yield | 1.7 ft³ kit (6 aggregate bags) |
| Working time | 32 minutes at 73°F |
| Thickness per lift | 1 to 6 in |
| Effective bearing area | > 95% |
| Compressive strength | 15,800 psi at 1 day; 17,500 psi at 28 days |
| Bond strength | 3,900 psi at 28 days |
| Peak exotherm | 168°F at 65 minutes |
| Packaging | 1.7 ft³ kit |
| Shelf life | 2 years unopened |
Product documents: E3-Xtreme Technical Data Sheet
Frequently Asked Questions
When should I use Euclid E3-Xtreme?
Use Euclid E3-Xtreme for high dynamic load grouting. Euclid lists pumps and rotating equipment, wind turbine bases and crane rails, compressors and turbo-machinery, skid-mounted equipment, and presses and stamping machines.
What type of epoxy grout is Euclid E3-Xtreme?
Euclid publishes Euclid E3-Xtreme as a three-component, high-flow, ultra-high-strength epoxy grout.
What effective bearing area does Euclid E3-Xtreme achieve against a baseplate?
Euclid rates Euclid E3-Xtreme at greater than 95% effective bearing area, meaning the grout contacts the plate instead of leaving voids.
How thick can Euclid E3-Xtreme be placed in one lift?
Euclid publishes a 1 in minimum and 6 in maximum per lift for Euclid E3-Xtreme in a large mass.
What compressive strength does Euclid E3-Xtreme reach?
Euclid publishes 15,800 psi at 1 day and 17,500 psi at 28 days at 73°F.
What working time does Euclid E3-Xtreme have at 73°F?
Euclid publishes about 32 minutes working time at 73°F on Euclid E3-Xtreme.
