Euclid Aquaseal LVS 2.0 Cubic Foot Unit
Aquaseal LVS is a three-component, low-viscosity epoxy grout kit for structural pile encapsulation and marine jacket grouting.
- 2.0 cubic foot pre-proportioned kit
- Flows into pile jackets above or below the waterline
- Bonds to concrete and steel in marine work
$450.44
Euclid Aquaseal LVS Pile Jacket Grout, 2.0 CF Kit
Aquaseal LVS is a three-component, low-viscosity epoxy grout kit for structural pile encapsulation and marine jacket grouting. The 100% solids resin and hardener wet out graded silica aggregate and flow into jackets above or below the waterline on piers, bridge columns, and similar marine repairs. Each 2.0 cubic foot kit is pre-proportioned. Mix 3:2 resin to hardener by volume. Gel time about 45 to 60 minutes at 75°F.
Key Features
- Low-viscosity epoxy grout for pile jackets and marine encapsulation
- Pre-proportioned 2.0 cubic foot kit for consistent jobsite mixing
- Flows into jackets and displaces water as the mass is placed
- Bonds to prepared concrete and steel above or below the waterline
- 100% solids epoxy resin, hardener, and graded silica aggregate
- Gel time about 45 to 60 minutes at 75°F
Applications
- Structural pile encapsulation
- Bridge columns, piers, and marine jacket grouting
- Above- and below-waterline marine repairs
- Where a flowing epoxy grout is needed in a confined jacket
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Euclid Chemical |
| Product | Aquaseal LVS |
| Type | Low-viscosity epoxy pile grout |
| Mix ratio | 3:2 by volume (A:B) |
| Gel time | 45 to 60 min (100 g at 75°F) |
| Compressive strength, mortar | 8,000 psi |
| Compressive strength, neat | 7,000 psi |
| Shear bond | 2,500 psi (concrete failure) |
| Yield | 2.0 ft³ per kit |
| Min water temp | 50°F |
| Shelf life | 2 years unopened |
Frequently Asked Questions
What is in the 2.0 CF kit?
A pre-proportioned unit with Part A resin, Part B hardener, and graded silica aggregate sized to yield about 2.0 cubic feet when mixed.
Where is Aquaseal LVS used?
Pile jackets and marine encapsulation on piers, bridge columns, and similar structures, above or below the waterline.
Is a current Euclid PDF posted?
Euclid Chemical's current public TDS covers Aquaseal Gel, LV, and MV. No current Aquaseal LVS PDF is posted on euclidchemical.com.
