Simpson Strong-Tie Drop-In (DIAB) Internally Threaded Anchor Lipped 3/8 Case 50 DIABL37
DIAB 3/8 in lipped drop-in, model DIABL37. Box of 50. Drill 1/2 in. UNC 16. Lip seats at the surface.
- 3/8 in lipped, model DIABL37, box of 50
- Drill 1/2 in; lip seats at the surface
- Flush UNC 3/8 in listed separately
$16.21
Availability:
In stock
Drop Shipped DIAB Lipped Drop-In 3/8, DIABL37
DIABL37 is the 3/8 in lipped drop-in. The lip stops the insert at the surface. Zinc-plated carbon steel for solid concrete. Box of 50. Drill 1/2 in to the 1 9/16 in body length and drive the plug until the setting-tool shoulder seats. UNC 16 threads. Live lipped sizes are 1/4, 3/8, and 1/2. Flush UNC 3/8 in is listed separately. Follow the current Simpson Strong-Tie drop-in data on the job.
Looking for another size?
Key Features
- Lipped drop-in so the insert stops at the surface
- 3/8 in, model DIABL37, box of 50
- Drill 1/2 in to 1 9/16 in body length; UNC 16
- Set with the matching setting tool until the shoulder seats
- Flush UNC DIAB37 listed separately
Applications
- Flush-finish inserts where a lip is specified
- 3/8 in UNC rod in concrete
- Jobs that want the insert stopped at the surface
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Simpson Strong-Tie |
| Product | DIAB Lipped |
| Model | DIABL37 |
| Rod | 3/8 in UNC 16 |
| Drill bit | 1/2 in |
| Body length | 1 9/16 in |
| Box qty | 50 |
| Style | Lipped |
| Other lipped | 1/4 and 1/2, live |
| Not | Flush UNC or coil-thread |
Frequently Asked Questions
Lipped or flush?
Lipped. Flush UNC DIAB37 is listed separately.
How do I set it?
Drill 1/2 in to 1 9/16 in, seat the lip, drive the setting tool until the shoulder seats.
What other lipped sizes are live?
1/4, 3/8, and 1/2. No live 5/8 or 3/4 lipped.
Coil-thread 3/8?
Not live.
Who makes it?
Simpson Strong-Tie.
