Sika Sikaflow 649 High-Flow Epoxy Grout 1.7CF
SikaFlow 649 grout is a high-performance epoxy grout used for the support of heavy equipment. It ensures the proper transmission of static and dynamic loads to the equipment foundation.
- High early and ultimate strengths
- Excellent 85% bearing area
- Durable bond to concrete and steel
$476.54
SKU
20120
SikaFlow 649 – High-Strength, High-Flow Epoxy Grout (1.7 CF Unit)
SikaFlow 649 is a precision, three-component epoxy grout engineered for the demanding needs of heavy equipment support and high-torque applications. It features high early and ultimate compressive strengths, excellent flow characteristics, and superior load-bearing capacity—making it ideal for use in grouting compressors, generators, turbines, pumps, and rotating machinery. SikaFlow 649 withstands elevated service temperatures and dynamic loads, making it suitable for crane rails, crusher ball mills, and wind turbine bases. Its ability to deliver consistent placement even in thin pours and extended distances ensures superior performance in critical baseplate applications.
Key Features:
- High compressive strength up to 20,000 psi in 96 hours
- High flow for long-distance and thin-pour applications
- Meets API 610 and API RP 686 standards for rotating equipment
- Withstands high service temperatures up to 155°F (68°C)
- Excellent bond to concrete and steel surfaces
- Resists impact, torque, vibration, and chemical exposure
- Can be pumped or poured for flexible installation
- Suitable for critical baseplate and anchor bolt grouting
Applications:
- Precision alignment of compressors, turbines, and generators
- Baseplate grouting for pumps, motors, and heavy machinery
- Grouting wind turbine tower bases
- Post-tensioning pour-back grouting
- Crusher mills, slab tables, crane rails, and anchor bolt grouting
Technical Specifications:
| Property | Value |
|---|---|
| Compressive Strength (73°F) | 24 hrs: 11,500 psi, 48 hrs: 16,400 psi, 96 hrs: 18,000 psi |
| Flexural Strength | Up to 4,600 psi @ 76°F |
| Tensile Strength | 2,300 psi (ASTM C307) |
| Bond Strength to Steel | Up to 3,100 psi (Tensile) / 5,000 psi (Slant Shear) |
| Modulus of Elasticity | Up to 2.6 x 10⁶ psi (18 GPa) |
| Thermal Expansion | 11.8 x 10⁻⁶ to 21.8 x 10⁻⁶ in/in/°F |
| Water Absorption | 0.076% |
| Coverage | 1.73 ft³ per full unit (3-bag high flow: 1.35 ft³) |
| Mix Ratio | Variable aggregate fill 5.06:1 to 6.75:1 |
| Working Time | 90–120 min @ 70°F |
Frequently Asked Questions:
Can SikaFlow 649 be used in high-temperature equipment bases?
Yes, SikaFlow 649 is specifically designed for high-temperature service and meets API standards for rotating equipment.
What is the minimum and maximum pour thickness?
Minimum placement thickness is ½ inch. For lifts over 6 inches, consult your Sika representative.
Can this grout be pumped?
Yes, SikaFlow 649 is pumpable using peristaltic or piston pumps and can be conveyed up to 50 ft. High-flow mixes are easier to pump than standard full-bag mixes.
| Brand | Sika |
|---|---|
| Manufacturer | Sika |
