Sylmasta SylWrap Universal Pipe Repair Kit 75mm x 2.7m SylWrap
Sylmasta SylWrap Universal Pipe Repair Kit SYL-309-UP pairs Wrap & Seal, Superfast Epoxy Putty, and a 75mm x 2.7m SylWrap HD bandage for live-leak repairs on approximately 25-50mm outside diameter pipe. Seal the leak with tape under pressure or putty with the line off, then overwrap SylWrap HD for a WRAS-listed composite repair on steel, copper, plastics, and plant pipework.
- WRAS Approval lists the Universal Kit as suitable for pipes and fittings carrying drinking water.
- SylWrap HD working time is 2 to 5 minutes, with a functional cure in 30 to 45 minutes after water activation.
- Bonds to steel, copper, iron, GRP, ceramics, clay, most plastics, concrete, rubber, and lead, including elbows and tees.
$88.36
Availability:
In stock
( 1 Available )
Sylmasta SylWrap Universal Pipe Repair Kit - 75mm x 2.7m
Sylmasta SylWrap Universal Pipe Repair Kit is a live-leak repair kit supplied as SYL-309-UP with a 75mm x 2.7m SylWrap HD bandage for pipes of approximately 25-50mm outside diameter. The kit carries Wrap & Seal, Superfast Epoxy Putty, and SylWrap HD so a leaking line can be sealed and reinforced without tools, including elbows and tees, with a WRAS-listed overwrap and a functional cure in 30 to 45 minutes.
Looking for another size?
50mm x 1.8m
15-25mm OD 100mm x 3.6m
50-100mm OD 150mm x 5m
100-150mm OD 150mm x 10m
150-300mm OD 200mm x 20m
300-600mm OD
15-25mm OD 100mm x 3.6m
50-100mm OD 150mm x 5m
100-150mm OD 150mm x 10m
150-300mm OD 200mm x 20m
300-600mm OD
Key Features
- SYL-309-UP is sized for approximately 25-50mm outside diameter pipe, with a 75mm x 2.7m SylWrap HD bandage and 25mm x 2m Wrap & Seal.
- Live leaks are sealed with self-fusing Wrap & Seal; a single tape wrap on this OD range is listed at 25 bar on 25mm pipe and 12 bar on 50mm pipe.
- When pressure can be turned off, Superfast Epoxy Putty fills holes and cracks with a watertight material that, with SylWrap HD, can reach 30 bar / 435 psi once the leak path is filled and wrapped.
- Water-activated SylWrap HD sets into an impact-resistant protective shell around the initial seal.
- WRAS Approval lists the Universal Kit as suitable for pipes and fittings carrying drinking water.
- Service temperature capability reaches 200°C / 390°F on hot water and chemical lines.
- Effective on elbows, tees, saddles, and other complex shapes as well as straight runs.
Technical Specifications
| Property | Value |
|---|---|
| Product code | SYL-309-UP |
| SylWrap HD bandage | 75mm x 2.7m |
| Wrap & Seal tape | 25mm x 2m |
| Pipe diameter | 25-50mm |
| SylPad | Not included |
| Max live leak pressure (1 x Wrap & Seal) | 25mm: 25 bar / 50mm: 12 bar |
| Max pressure (putty + SylWrap HD) | 30 bar / 435 psi once leak path is filled and wrapped |
| Working time (SylWrap HD) | 2–5 minutes (temperature dependent) |
| Functional cure | 30–45 minutes |
| Max service temperature | 200°C / 390°F |
Product documents: Sylmasta SylWrap Universal Pipe Repair Kit Technical Data Sheet
Frequently Asked Questions
Which sites and pipe services call for the Sylmasta SylWrap Universal Pipe Repair Kit?
Sylmasta SylWrap Universal Pipe Repair Kit permanently repairs leaking pipes even when pressure cannot be turned off. Typical work includes water and wastewater supply and treatment leaks, petrochemical gas, oil, and water lines, quarry wash-plant pipework, power-station cooling and ash lines, steelworks steam and slurry pipes, hospitality heating and air-conditioning lines, marine fuel, water, and waste pipes, and domestic water or rubber hose leaks. Repairs can be completed in under 30 minutes on steel, copper, plastics, and other plant substrates.
What is the seal-then-overwrap sequence for Sylmasta SylWrap Universal Pipe Repair Kit with pressure on or off?
If pressure cannot be turned off, stretch Wrap & Seal to three times its length and wrap it over the leak so it fuses into a solid rubber band that holds pressure. If pressure can be turned off, knead Superfast Epoxy Putty to a uniform colour and push it into holes and cracks; it hardens in 5 to 10 minutes. In both cases, wet SylWrap HD to activate the resin, wrap and smooth it over the seal, and allow a 2 to 5 minute work window with a functional cure in 30 to 45 minutes. Wear plastic gloves and follow the Safety Data Sheets.
How do I match the Sylmasta SylWrap Universal Pipe Repair Kit 75mm x 2.7m (SYL-309-UP) to my pipe OD?
Specify Sylmasta SylWrap Universal Pipe Repair Kit (SYL-309-UP) when you need a 75mm x 2.7m SylWrap HD bandage for pipes of approximately 25-50mm outside diameter. The narrower 50mm x 1.8m sister (SYL-206-UP) covers 15-25mm OD. Step up to SYL-412-UP for 50-100mm OD, or to SYL-616-UP, SYL-633-UP, and SYL-866-UP for larger mains. Match wrap width and length to the TDS outside-diameter chart.
Does Sylmasta SylWrap Universal Pipe Repair Kit carry WRAS listing for potable water lines?
Yes. The SylWrap Universal Pipe Repair Kit has WRAS approval, so it is listed as suitable for pipes and fittings carrying drinking water. That supports potable-line leak repairs where a WRAS-listed material is required. Always follow site hygiene rules and confirm the finished repair meets the local water-system specification before returning the line to service.
How high can pressure and temperature go on a finished Sylmasta SylWrap Universal Kit repair?
Pressure-off Superfast putty plus SylWrap HD can reach 30 bar / 435 psi once the leak path is filled and wrapped. For a live leak using one Wrap & Seal, the TDS lists 25mm: 25 bar / 50mm: 12 bar. Extra fused tape layers can raise live-leak resistance. Maximum service temperature is 200°C / 390°F. Confirm hole size against the Wrap & Seal calculator if you are unsure how many tapes you need.
Which materials ship in the 75mm x 2.7m Universal Kit, and which substrates does it bond to?
The 75mm x 2.7m Universal Kit (SYL-309-UP) contains Superfast Epoxy Putty, 25mm x 2m Wrap & Seal Pipe Burst Tape, and a 75mm x 2.7m SylWrap HD Pipe Repair Bandage. SylPad is not included on SYL-309-UP. Use it on steel, copper, iron, GRP, ceramic, clay, most plastics, concrete, rubber, and lead. Wear plastic gloves when handling the putty and bandage, and keep the SylWrap HD foil pouch sealed until use.
