Sylmasta SylWrap Universal Pipe Repair Kit 150mm x 10m SylWrap
Sylmasta SylWrap Universal Pipe Repair Kit SYL-633-UP pairs Wrap & Seal, Superfast Epoxy Putty, a 150mm x 10m SylWrap HD bandage, and SylPad for live-leak repairs on approximately 150-300mm outside diameter pipe. Use SylPad to concentrate tape pressure over larger leaks, then overwrap SylWrap HD so the repair sets into an impact-resistant shell.
- WRAS Approval lists the Universal Kit as suitable for pipes and fittings carrying drinking water.
- SylPad multiplies Wrap & Seal pressure resistance on 150-300mm pipe so live leaks can be sealed without shutdown.
- Pressure-off Superfast putty plus SylWrap HD can reach 30 bar / 435 psi once the leak path is filled and wrapped.
$234.96
Availability:
Out of stock
Sylmasta SylWrap Universal Pipe Repair Kit - 150mm x 10m
Sylmasta SylWrap Universal Pipe Repair Kit is a live-leak repair kit supplied as SYL-633-UP with a 150mm x 10m SylWrap HD bandage for pipes of approximately 150-300mm outside diameter. Wrap & Seal, Superfast Epoxy Putty, SylWrap HD, and a SylPad pressure multiplier let crews concentrate tape over larger leaks, then overwrap a WRAS-listed composite shell for a repair in under 30 minutes.
Looking for another size?
50mm x 1.8m
15-25mm OD 75mm x 2.7m
25-50mm OD 100mm x 3.6m
50-100mm OD 150mm x 5m
100-150mm OD 200mm x 20m
300-600mm OD
15-25mm OD 75mm x 2.7m
25-50mm OD 100mm x 3.6m
50-100mm OD 150mm x 5m
100-150mm OD 200mm x 20m
300-600mm OD
Key Features
- SYL-633-UP is sized for approximately 150-300mm outside diameter pipe, with a 150mm x 10m SylWrap HD bandage and 50mm x 4m Wrap & Seal.
- SylPad is included to concentrate Wrap & Seal pressure over the leak on larger pipe and multiply tape resistance by up to three times.
- Live leaks can be sealed without shutdown; a single Wrap & Seal on this OD range is listed at 8 bar on 150mm pipe down to 4 bar on 300mm pipe.
- Superfast Epoxy Putty seals holes when pressure can be turned off, then SylWrap HD overwraps the repair.
- WRAS Approval lists the Universal Kit as suitable for pipes and fittings carrying drinking water.
- Functional cure in 30 to 45 minutes supports a permanent pipe repair in under 30 minutes per the TDS.
- Applies to steel, copper, malleable iron, GRP, ceramic, clay, most plastics, concrete, rubber, and lead.
Technical Specifications
| Property | Value |
|---|---|
| Product code | SYL-633-UP |
| SylWrap HD bandage | 150mm x 10.0m |
| Wrap & Seal tape | 50mm x 4m |
| Pipe diameter | 150-300mm |
| SylPad | Included (multiplies Wrap & Seal pressure resistance) |
| Max live leak pressure (1 x Wrap & Seal) | 150mm: 8 bar / 225mm: 5 bar / 300mm: 4 bar |
| Max pressure (putty + SylWrap HD) | 30 bar / 435 psi (depends on leak) |
| Working time (SylWrap HD) | 2–5 minutes (temperature dependent) |
| Functional cure | 30–45 minutes |
| Max service temperature | 200°C / 390°F |
Product documents: Sylmasta SylWrap Universal Pipe Repair Kit Technical Data Sheet
Frequently Asked Questions
What leaking-pipe jobs is the Sylmasta SylWrap Universal Pipe Repair Kit built for?
Sylmasta SylWrap Universal Pipe Repair Kit permanently repairs leaking pipes even when pressure cannot be turned off. Typical work includes water and wastewater supply and treatment leaks, petrochemical gas, oil, and water lines, quarry wash-plant pipework, power-station cooling and ash lines, steelworks steam and slurry pipes, hospitality heating and air-conditioning lines, marine fuel, water, and waste pipes, and domestic water or rubber hose leaks. Repairs can be completed in under 30 minutes on steel, copper, plastics, and other plant substrates.
How do I use Sylmasta SylWrap Universal Pipe Repair Kit on a live leak versus a leak with pressure off?
If pressure cannot be turned off, stretch Wrap & Seal to three times its length and wrap it over the leak so it fuses into a solid rubber band that holds pressure. If pressure can be turned off, knead Superfast Epoxy Putty to a uniform colour and push it into holes and cracks; it hardens in 5 to 10 minutes. In both cases, wet SylWrap HD to activate the resin, wrap and smooth it over the seal, and allow a 2 to 5 minute work window with a functional cure in 30 to 45 minutes. Wear plastic gloves and follow the Safety Data Sheets.
When should I choose the SylWrap Universal Pipe Repair Kit 150mm x 10m (SYL-633-UP)?
Choose Sylmasta SylWrap Universal Pipe Repair Kit (SYL-633-UP) when you need a 150mm x 10m SylWrap HD bandage plus SylPad for pipes of approximately 150-300mm outside diameter. The shorter 150mm x 5m sister (SYL-616-UP) covers 100-150mm OD without SylPad. The 200mm x 20m kit (SYL-866-UP) steps up for 300-600mm OD. Confirm OD against the Universal Kit TDS size table before specifying.
Is Sylmasta SylWrap Universal Pipe Repair Kit approved for drinking-water pipes?
Yes. The SylWrap Universal Pipe Repair Kit has WRAS approval, so it is listed as suitable for pipes and fittings carrying drinking water. That supports potable-line leak repairs where a WRAS-listed material is required. Always follow site hygiene rules and confirm the finished repair meets the local water-system specification before returning the line to service.
What pressure and temperature can a completed SylWrap Universal Kit repair handle?
With putty and SylWrap HD, maximum pressure resistance is 30 bar / 435 psi depending on the leak. For a live leak using one Wrap & Seal, the TDS lists 150mm: 8 bar / 225mm: 5 bar / 300mm: 4 bar. This kit includes SylPad, which is used with Wrap & Seal to concentrate tape pressure over the leak and multiply pressure resistance by up to three times. Maximum service temperature is 200°C / 390°F.
What is inside the 150mm x 10m Universal Kit, and which pipe materials can it repair?
The 150mm x 10m Universal Kit (SYL-633-UP) contains Superfast Epoxy Putty, 50mm x 4m Wrap & Seal Pipe Burst Tape, a 150mm x 10.0m SylWrap HD Pipe Repair Bandage, and a SylPad Pressure Resistance Multiplier. Kits covering pipes over 150mm diameter include SylPad per the TDS. Substrates include steel, copper, malleable iron, GRP, ceramic, clay, most plastics, concrete, rubber, and lead.
