Sika Greenstreak Flexible PVC Waterstop Dumbbell 746 6in x 3/16in DB 100ft Roll
Sika Greenstreak PVC Waterstop 746 is a dumbbell profile in a 6 in by 3/16 in 100 ft roll. Embedded across non-moving construction joints, it forms a watertight diaphragm with more flange than the 4 in 741.
- Dumbbell profile for non-moving construction joints
- 6 in by 3/16 in web with 3/8 in dumbbell ends
- 100 ft roll, rated 75 ft of hydrostatic head
$316.92
Sika Greenstreak PVC Waterstop 746
Sika Greenstreak Flexible PVC Waterstop profile 746 is a dumbbell PVC strip for embedded waterproofing at non-moving construction joints. This 6 in by 3/16 in profile ships as a 100 ft roll (part 419543) and forms a watertight diaphragm in cast-in-place concrete. The wider flange vs 741 gives more embedment in foundations, retaining walls, and slabs where movement is negligible.
Key Features
- Flexible PVC waterstop, profile 746 dumbbell
- Profile width 6 in with 3/16 in web thickness
- Weight approximately 0.71 lb/ft
- Head pressure 75 ft (224 kPa)
- NSF/ANSI 61 approved for potable water contact
- Meets Corps of Engineers CRD-C 572-74 physical properties
Applications
- Non-moving construction joints with continuous reinforcement
- Foundations and retaining walls
- Tunnels and below-grade walls
- Tanks and containment where joint movement is negligible
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Sika Greenstreak |
| Product | Flexible PVC Waterstop 746 Dumbbell |
| Part no. | 419543 |
| Unit | 100 ft roll |
| Profile | 6 in x 3/16 in dumbbell, 3/8 in ends |
| Weight | Approximately 0.71 lb/ft |
| Head pressure | 75 ft (224 kPa) |
| Tensile strength | 2,000 psi min (ASTM D638) |
| Elongation | 350% (ASTM D638) |
| Shore A | 79 +/- 3 (ASTM D2240) |
| Potable water | NSF/ANSI 61 |
Product documents: Greenstreak PVC Waterstop Product Data Sheet (PDF)
Frequently Asked Questions
What joints suit Sika Greenstreak PVC Waterstop 746?
Non-moving construction joints that need a 6 in dumbbell diaphragm instead of the 4 in 741.
What size is Sika Greenstreak PVC Waterstop 746?
The roll is 100 ft of 6 in by 3/16 in dumbbell profile, part 419543.
What head pressure does Sika Greenstreak PVC Waterstop 746 hold?
75 ft (224 kPa) from the Greenstreak profile table.
What profile is Sika Greenstreak PVC Waterstop 746?
Dumbbell, 6 in wide with a 3/16 in web and 3/8 in ends, approximately 0.71 lb/ft.
What Corps specification does Sika Greenstreak PVC Waterstop 746 meet?
Physical property requirements of Army Corps of Engineers CRD-C 572-74.
What 741 difference does Sika Greenstreak PVC Waterstop 746 have?
Same dumbbell family, 2 in wider flange and a 75 ft head rating versus 65 ft on 741.
