Trico Optomatic Oiler 316 SS 8oz Bottom 30215
Trico Opto-Matic 30215. 8 oz 316 stainless constant-level oiler with a one-piece glass reservoir for corrosive sumps.
- 8 oz, 1/4 NPT, 250 F continuous
- 316 stainless casting; one-piece glass
- 4 oz and 16 oz 316 SS are other sizes
$424.31
Availability:
In stock
Drop Shipped Trico Opto-Matic 30215, 8 oz 316 Stainless
Trico Opto-Matic 30215 is a 316 stainless constant-level oiler with a one-piece glass reservoir. Use it on pump bearing housings and gearboxes in corrosive plants. 8 oz, 1/4 NPT, 250 F continuous. Adjustable level. Viton o-ring. Magento still names this 8 oz Bottom. The 4 oz and 16 oz 316 stainless oilers are other sizes of this oiler. Zinc glass oilers are listed separately.
Looking for another size?
Key Features
- 316 stainless constant-level oiler, 8 oz
- One-piece glass reservoir; Viton o-ring
- 1/4 NPT; 250 F continuous
- Adjustable oil level
- 4 oz and 16 oz 316 SS are other sizes
- Not zinc glass or closed-system
Applications
- Corrosive pump bearing housings
- Gearboxes in chemical and pulp plants
- Oil sumps that need 316 stainless
Technical Specifications
| Property | Value |
|---|---|
| Manufacturer | Trico |
| Model | 30215 |
| Style | Opto-Matic glass, 316 SS |
| Capacity | 8 oz |
| Connection | 1/4 NPT |
| Max temp | 250 F continuous |
| Reservoir | one-piece glass |
| Casting | 316 stainless |
| O-ring | Viton |
| Other sizes | 4 oz 30213, 16 oz 30220 |
| Magento name | leftover 8 oz Bottom |
Frequently Asked Questions
What is this?
Trico Opto-Matic 30215, an 8 oz 316 stainless constant-level oiler.
Bottom in the name?
Magento leftover. Published model is 8 oz 316 SS 30215.
Other sizes?
4 oz 30213 and 16 oz 30220.
Temp?
250 F continuous.
Who makes it?
Trico.
